Fixture Update Request: Mobile Bar Light 1 (SP2P2H2) - 36CH & 66CH Modes

Fixture Update Request: Mobile Bar Light 1 (SP2P2H2) - 36CH & 66CH Modes

Jannik Sülzle

Fixture Update Request: Mobile Bar Light 1 (SP2P2H2) - 36CH & 66CH Modes

Hello Pioneer DJ Team / AtlaBase Team,


I am using a DDJ-FLX10 with Rekordbox Lighting and recently purchased two "Mobile Bar Light 1" units (Model: SP2P2H2).


While the fixture is already in the database, the current mapping seems to be incorrect for my units. The colors do not match the software selection (e.g., selecting Red triggers Blue), the motor movements are jerky/incorrect, and the auto-modes on the higher channels (Channel 34 in 36CH mode / Channel 64 in 66CH mode) are being triggered unintentionally, causing the light to go into a random standalone mode.


I have attached the official manual showing the correct DMX Channel Maps for the 18CH, 36CH, and 66CH modes.
Fixture Details:
•⁠  ⁠Manufacturer: Unknown / Generic (Alibaba)
•⁠  ⁠Model Name: Mobile Bar Light 1 (SP2P2H2)
•⁠  ⁠Link to current Database Entry: "Mobile Bar Light 1"


Please update the existing fixture profile or create a new one based on the attached DMX tables to ensure the color wheel values (Channels 6 & 16 in 36CH mode) and the motor controls work as intended.
Thank you for your help!
